ZYTC Alloy, a professional Chinese precision nickel alloy manufacturer, supplies premium AMS 5711 UNS N06635 Alloy S bars, forgings, flash welded rings and forging stock fully compliant with SAE AMS 5711 aerospace specification. AMS 5711 defines this corrosion and heat-resistant nickel base alloy with nominal chemical composition: 65Ni - 15.8Cr - 15.2Mo - 0.30Al - 0.05La, delivered in solution heat treated condition. Also known as Hastelloy S, UNS N06635 is engineered for service under extreme high-temperature and corrosive atmospheres, widely adopted for critical aerospace and high-end industrial hardware. Get a Custom Inquiry📧 Email: daisy@zytcsteel.com
📲 WhatsApp: +86 17335753350 |  |
Chemical Composition| Elements | Content (%) |
|---|
| Nickel, Ni | 67 | | Chromium, Cr | 14.5 - 17 | | Molybdenum, Mo | 14 - 16.5 | | Iron, Fe | 3 | | Cobalt, Co | 2 | | Tungsten, W | 1 | | Copper, Cu | 0.35 | | Manganese, Mn | 0.30 - 1.0 | | Silicon, Si | 0.20 - 0.75 | | Aluminum, Al | 0.10 - 0.50 | | Carbon, C | 0.020 | | Phosphorous, P | 0.020 | | Boron, B | 0.015 | | Sulfur, S | 0.015 | | Lanthanum, La | 0.010 - 0.10 |
Physical Properties| Properties | Metric | Imperial |
|---|
| Density | 8.75 g/cm³ | 0.316 lb/in³ | | Melting point | 1360°C | 2480°F |
Mechanical Properties| Properties | Metric | Imperial |
|---|
| Tensile strength (@ 1093°C/1999°F, thickness 1.10-1.60 mm/0.0433-0.0630 in.) | 110 MPa | 16000 psi | | Yield strength (@ 1093°C/1999°F, thickness 1.10-1.60 mm/0.0433-0.0630 in., 0.2% offset) | 52 MPa | 7540 psi | | Elastic modulus | 212 GPa | 30700 ksi | | Elongation at break (@ 982°C/1800°F, thickness 1.10-1.60 mm/0.0433-0.0630 in., in 50.8 mm) | 46% | 46% | | Charpy Impact (V Notch; solution heat-treated, not aged) | 190 J | 140 ft-lb |
Key Properties- Outstanding High-Temperature Oxidation & Sulfidation Resistance: Maintains stable performance against oxidation and sulfidation up to 980°C (1800°F), ideal for long-term exposure to high-temperature flue gas and sulfur-containing hot environments.
- Superior Creep & Stress Rupture Strength: Retains reliable mechanical integrity during repeated thermal cycling, resisting permanent deformation under sustained high-temperature load.
- Excellent Corrosion Resistance: Offers robust protection against aggressive sulfur-rich gaseous media and high-temperature corrosive atmospheres.
|  |
Processing & Specification Requirements- Heat Treatment: Solution annealed at approximately 1175°C (2150°F) followed by rapid cooling as required by AMS 5711.
- Fabrication Guidance: TIG welding with strict process control is recommended to prevent material sensitization. Machining should adopt dedicated cutting parameters for nickel-base alloys.
ApplicationsAerospace & Aviation Jet engine combustor components, turbine seals, exhaust assemblies and other hot-section critical parts. Chemical & Thermal Industrial High-temperature chemical processing equipment, furnace hardware, high-temperature reactor components working in corrosive gas environments. Get Your QuoteContact ZYTC Alloy with your drawing, dimension, tolerance and working condition requirements. Our technical team will provide professional material consultation and competitive quotation within 24 hours. 📧Email:daisy@zytcsteel.com
