Nickel Alloy 625 Strip (UNS N06625 / W.Nr. 2.4856) is a solid-solution-strengthened nickel-chromium-molybdenum-niobium alloy supplied in precision strip, foil, and coil forms. The addition of molybdenum and niobium provides exceptional corrosion resistance and high strength without requiring age-hardening treatments .

Inconel 625 strip offers a unique combination of properties – outstanding resistance to pitting, crevice corrosion, and chloride-ion stress-corrosion cracking, combined with excellent high-temperature strength up to 980°C (1,800°F) . It maintains good ductility and fabricability even in thin gauge forms.

As a leading Inconel 625 strip manufacturer and supplier, ZYTC Alloy offers precision strip products in a comprehensive range of thicknesses (0.05mm – 3.0mm) and widths (up to 600mm), with custom slitting, edging, and packaging options. Every shipment is fully traceable, documented, and compliant with international standards including ASTM B443, AMS 5599, and AMS 5869 .

Key Features:

✅ Solid-solution strengthened – no age hardening required
✅ Exceptional resistance to pitting and crevice corrosion
✅ Outstanding chloride-ion stress-corrosion cracking resistance
✅ High strength from cryogenic to 980°C (1,800°F)
✅ Excellent oxidation resistance
✅ Good fabricability – can be formed, welded, and deep drawn
✅ Non-magnetic in annealed condition
✅ Good fatigue strength and ductility

Technical Specifications

Chemical Composition (UNS N06625)

Element	Content (%)	Element	Content (%)
Nickel (Ni)	58.0 min	Manganese (Mn)	≤ 0.50
Chromium (Cr)	20.0 – 23.0	Silicon (Si)	≤ 0.50
Molybdenum (Mo)	8.0 – 10.0	Phosphorus (P)	≤ 0.015
Iron (Fe)	≤ 5.0	Sulfur (S)	≤ 0.015
Niobium + Tantalum (Nb+Ta)	3.15 – 4.15	Aluminum (Al)	≤ 0.40
Cobalt (Co)	≤ 1.0	Titanium (Ti)	≤ 0.40
Carbon (C)	≤ 0.10	Copper (Cu)	≤ 0.07

Strip Specifications

Parameter	Range
Thickness	0.05mm – 3.0mm
Width	1.0mm – 600mm
Edge Condition	Slit / Deburred / Round
Surface Finish	Bright, smooth, free from scratches and impurities
Coil ID	200mm, 300mm, 400mm, 500mm (customizable)
Packaging	Waterproof paper winding + PVC film + wooden pallet/case

Mechanical Properties (Annealed – Thickness ≤ 4.76mm)

Property	Value
Tensile Strength	≥ 690 MPa (100 ksi)
Yield Strength (0.2% Offset)	≥ 275 – 345 MPa
Elongation	≥ 30%
Hardness	70 – 90 HRB

Physical Properties

Property	Value
Density	8.44 g/cm³ (0.305 lb/in³)
Melting Range	1,290 – 1,350°C (2,350 – 2,460°F)
Maximum Service Temperature	980°C (1,800°F)
Modulus of Elasticity	~207 GPa (30,000 ksi)
Thermal Conductivity (20°C)	~9.8 W/m·K

Available Strip Products

ZYTC Alloy offers Inconel 625 in precision strip, foil, and coil forms to meet diverse industrial requirements.

Product Form	Thickness Range	Width Range	Applications
Foil	0.05mm – 0.15mm	Up to 400mm	Honeycomb, seals, diaphragms
Precision Strip	0.15mm – 1.0mm	Up to 600mm	Springs, bellows, shims
Coil Strip	0.5mm – 3.0mm	Up to 600mm	Formed components, heat exchangers
Slit Coil	Custom	Custom width	Custom parts, stamping

Standards

Standard	Specification
ASTM B443	Plate, Sheet, and Strip (UNS N06625)
AMS 5599	Sheet, Strip, and Plate – Inconel 625
AMS 5869	Foil – Inconel 625
ASME SB-443	Pressure Vessel Applications
UNS	N06625
W.Nr.	2.4856
GB/T	GH3625

Applications

Nickel alloy 625 strip is widely used in demanding applications where thin gauge material must withstand high temperatures, corrosion, or stress .

Aerospace

Aircraft ducting systems, jet engine exhaust systems, honeycomb seals, bellows, turbine shroud rings, thrust reverser systems, and fuel/hydraulic lines.

Marine & Offshore

Seawater components, propeller blades, exhaust systems, fasteners, and marine platform equipment .

Chemical Processing

Heat exchanger plates, reactor linings, pollution control equipment, FGD systems, and chemical processing equipment .

Power Generation

Land-based turbine components, heat exchangers, and nuclear reactor components .

Automotive

Exhaust components, turbocharger parts, and high-temperature gaskets.

Industrial

Springs, seals, bellows, diaphragms, and precision formed parts

Quality Assurance

Quality is at the core of everything we do at ZYTC Alloy. Our comprehensive quality assurance system ensures that every strip product leaving our facility meets or exceeds your expectations.

Certifications & Compliance

Certification / Standard	Description
AS9120B	Aerospace Quality Management System
ISO9001:2015	International Quality Management System
ASTM B443	Nickel Alloy Sheet, Strip, and Plate
AMS 5599 / 5869	Aerospace Material Specifications
EN 10204 Type 3.1 / 3.2	Material Certification Document Types
