AMS 5596 is a leading aerospace material specification that governs corrosion and heat-resistant Alloy 718 (Inconel 718 / UNS N07718 / 2.4668) in sheet, strip, foil and plate forms with a maximum thickness of 1.00 inch (25.4 mm). As a versatile precipitation-hardening nickel-chromium superalloy strengthened with niobium, molybdenum, titanium and aluminum, Alloy 718 delivers exceptional tensile strength, creep-rupture resistance and thermal stability at elevated temperatures up to 704°C (1300°F). Distinguished from other high-temperature superalloys, AMS 5596 718 sheet features a sluggish age-hardening response, allowing safe annealing and welding operations without spontaneous hardening or post-weld cracking. It also offers reliable cryogenic performance down to -253°C, paired with excellent oxidation and corrosion resistance. As a trusted China nickel superalloy supplier,ZYTC Alloy provides fully AMS 5596 compliant Alloy 718 sheets and plates with precise dimensional tolerance, stable batch consistency and full industry certification support. | |
Full Industry Specification CoverageZYTC Alloy’s Alloy 718 products strictly comply with complete global aerospace and industrial standard systems, covering sheets, plates, tubes, bars, forgings and welding wires: Sheet, Strip & Plate: AMS 5596, AMS 5597, ASTM B670 Seamless Tube: AMS 5589, AMS 5590 Bar, Forging & Ring: AMS 5662, AMS 5663, AMS 5664, ASTM B637 Welding Wire: AMS 5832 Material Grade Standard: UNS N07718, Werkstoff Nr 2.4668
Chemical Composition| Element | Content (Wt%) |
|---|
| Nickel (Ni) | 50.0 – 55.0 | | Chromium (Cr) | 17.0 – 21.0 | | Iron (Fe) | Balance | | Niobium (Nb) | 4.75 – 5.50 | | Molybdenum (Mo) | 2.80 – 3.30 | | Titanium (Ti) | 0.65 – 1.15 | | Aluminum (Al) | 0.20 – 0.80 | | Cobalt (Co) | 1.0 max. | | Carbon (C) | 0.08 max. |
Physical & Mechanical Properties| Physical Property | Metric | Imperial |
|---|
| Density | 8.19 g/cm³ | 0.296 lb/in³ | | Modulus of Elasticity | 205 GPa | 29,700 ksi | | Coefficient of Expansion (20-100°C) | 13.0 µm/m·°C | 7.2 µin/in·°F |
Mechanical Properties (Solution Treated & Aged – AMS 5596): | Property | Metric | Imperial |
|---|
| Tensile Strength (min.) | 1240 MPa | 180 ksi | | Yield Strength (0.2% offset, min.) | 1034 MPa | 150 ksi | | Elongation (min.) | 12% | 12% |
High-Temperature Tensile Strength (Typical – Aged): | Temperature | Tensile Strength | Yield Strength |
|---|
| 540°C (1000°F) | 1170 MPa (170 ksi) | 1034 MPa (150 ksi) | | 650°C (1200°F) | 1100 MPa (160 ksi) | 965 MPa (140 ksi) | | 760°C (1400°F) | 860 MPa (125 ksi) | 690 MPa (100 ksi) |
Heat Treatment| Process | Temperature | Time | Cooling |
|---|
| Solution Annealing | 968°C (1775°F) | — | Rapid cool | | Precipitation Hardening (Aging) | 718-732°C (1325-1350°F) | 8 hours | Furnace cool to 621°C (1150°F), hold 8-18 hours, air cool |
ApplicationsThanks to its balanced high-temperature strength, excellent processability and corrosion resistance, AMS 5596 Alloy 718 sheet is widely adopted in high-reliability industrial and aerospace core components: Aerospace Industry: Jet engine structural components, turbine parts and high-temperature aviation assemblies Power Generation: Industrial gas turbine engines, thermal power equipment and high-temperature pressure components Oil & Gas Sector: Downhole wellhead components, high-pressure corrosion-resistant fixtures and exploration equipment parts Precision Mechanical Manufacturing: High-strength heat-resistant fasteners, complex stamped and formed structural parts
ZYTC Alloy Supply CapabilityZYTC Alloy maintains abundant spot inventory of AMS 5596 Alloy 718 sheets in diverse conventional sizes. Equipped with in-house precision guillotine cutting equipment, we provide custom size processing with ultra-tight dimensional tolerances, fully meeting customized manufacturing requirements for aerospace, energy and industrial clients. All products undergo strict PMI testing, mechanical property inspection and surface quality control to ensure full compliance with AMS and ASTM specifications. Why Choose ZYTC Alloy AMS 5596 718 Nickel AlloyFull standard compliance: 100% meets AMS 5596 aerospace specifications with stable high-temperature creep and rupture performance Strict quality control: Uniform microstructure, low defect rate and excellent batch-to-batch consistency One-stop service: Spot inventory + custom precision cutting + full certification delivery Multi-scenario material support: Complete 718 product portfolio covering sheets, tubes, bars, forgings and welding wires
Contact ZYTC Alloy TodayRequest a quote for AMS 5596 / 718 Nickel Alloy Sheet (UNS N07718 / 2.4668) – Precipitation-Hardenable Superalloy – Exceptional Strength & Creep Resistance. Please provide: Thickness, width, and length required Product form (sheet / strip / pipe / plate) Condition (annealed / aged) Quantity Destination port Any special certification requirements
