Evanohm 6J22 Alloy Wire – High-Precision Resistance Alloy

Evanohm 6J22 (6J22) is a high-precision nickel-chromium-aluminum-iron resistance wire with low TCR, high resistivity, and wide operating range (-60°C to +300°C).

Quantity :

Contact Now

Evanohm 6J22 (6J22) is a high-performance nickel-chromium-aluminum-iron resistance alloy widely recognized for its exceptional electrical stability, low temperature coefficient of resistance (TCR), and superior oxidation resistance. It is a preferred material for precision resistance elements, strain gauges, and high-reliability electronic components in aerospace, defense, and instrumentation industries.

ZYTC Alloy, a leading Chinese nickel alloy supplier, maintains an extensive inventory of Evanohm 6J22 alloy wire in stock, enabling fast delivery and cost-effective secondary processing for global clients.

Chemical Composition (Typical)

Element	Content (Wt%)
Nickel (Ni)	Balance
Chromium (Cr)	18.0 – 20.0
Aluminum (Al)	2.5 – 3.5
Iron (Fe)	2.0 – 3.0
Manganese (Mn)	≤ 0.50
Silicon (Si)	≤ 0.30

Evanohm 6J22 Alloy Wire Physical Properties

Grade	Density(g/cm3)	EMF vs Pt(0-100ºC)μv/ºC	Max using Temp (ºC)	Volume resistivity(μΩ.m)	PPM value (×10-6/ºC)
6J22	8.1	≤2.5	≤300	1.33±8%(20ºC)	≤±30(20ºC)

Core Composition & Superior Electrical Properties of Evanohm 6J22

Also known as Karma alloy, Evanohm 6J22 is a nickel-chromium-aluminum-iron precision resistance alloy with balanced copper, nickel, aluminum and iron elemental ratios. Compared with widely used Manganin resistance alloy, 6J22 boasts multiple decisive technical strengths:

Its resistivity reaches 2–3 times higher than Manganin, enabling thinner wire designs for compact micro-resistance elements;
Ultra-low temperature coefficient of resistance (TCR) and minimal thermal EMF vs copper, eliminating measurement deviation in precision circuits;
Excellent long-term resistance stability, with nearly zero resistance drift under continuous service;
Outstanding high-temperature oxidation resistance, supporting a much wider working temperature range of -60°C to 300°C, far exceeding Manganin’s temperature limit.

Thanks to these stable electrical features, Evanohm 6J22 wire is the primary raw material for fine precision resistors, strain foil, strain gauges and high-precision sensor components used in aerospace, industrial measurement and new energy equipment.

As a reliable China nickel alloy supplier, ZYTC Alloy strictly controls element ratios and trace impurity content of all in-stock 6J22 wire, guaranteeing consistent resistivity and TCR performance across every production batch to meet high-precision electronic manufacturing demands.

6J22 Alloy Wire Industry Standards

AMS 5989/4 Standard for Nickel Base Alloy Bars, Wire, Forgings, and Stock Forms

This standard is often referenced for high-performance nickel-chromium alloys used in aerospace and defense applications.
It emphasizes material purity and mechanical consistency.

Why Source In-Stock Evanohm 6J22 Wire from ZYTC Alloy

Abundant ready stock of 6J22 wire in multiple diameter specifications, supporting small-batch trial orders and mass bulk supply to avoid long custom production cycles;
Strictly follows AMS 5989/4 aerospace material standards, with full quality traceability for global industrial buyers;
One-stop secondary processing service: wire cutting, winding, flat strip rolling and foil slitting to reduce customers’ extra machining procedures;
Decades of nickel alloy production experience, stable export channels serving precision electronics, aerospace and sensor manufacturers worldwide as a trusted China nickel alloy supplier.

Contact ZYTC Alloy Today

📧 Email: daisy@zytcsteel.com
📲 WhatsApp: +86 17335753350

For inquiries, technical datasheets, or a competitive quote, contact our sales team. We are ready to support your precision resistance project with certified Evanohm 6J22 alloy wire from our extensive stock inventory.
