ASTM B865 specification covers UNS N05500 (Monel K-500) nickel-copper-aluminum alloy in the form of rounds, squares, hexagons, rectangles, forgings, forging stock, and cold-worked wire. This precipitation-hardenable alloy combines the excellent corrosion resistance of Monel 400 with significantly higher strength and hardness, achieved through the addition of aluminum and titanium followed by controlled heat treatment. Monel K-500 is the material of choice for pump shafts, valve stems, marine propeller shafts, oil well tools, fasteners, and springs requiring both high mechanical strength and outstanding corrosion resistance in seawater and chemical environments.
Chemical Composition (%)| Element | Composition Requirement |
|---|
| Nickel (Ni) | Minimum 63% | | Copper (Cu) | 27.0% ~ 33.0% | | Iron (Fe) | Maximum 2.0 | | Manganese (Mn) | Maximum 1.5 | | Carbon (C) | Maximum 0.18 | | Silicon (Si) | Maximum 0.50 | | Sulfur (S) | Maximum 0.010 | | Aluminum (Al) | 2.30 ~ 3.15 | | Titanium (Ti) | 0.35 ~ 0.85 |
Mechanical Properties| Property | Value Requirement |
|---|
| Tensile Strength (MPa) | Minimum 965 | | Yield Strength (MPa) | Minimum 690 | | Elongation (%) | Minimum 20 | | Hardness (HRC) | Minimum 27 |
Available ShapesRound, hexagonal, square, and rectangular shapes, as well as forged rings and discs.
Heat TreatmentMonel K-500 requires precipitation hardening (aging) to achieve its full mechanical properties : | Process | Temperature | Time | Cooling |
|---|
| Aging (Precipitation Hardening) | 580-590°C (1075-1095°F) | 8-10 hours | Air cool | | Spring Temper + Aging | 530-540°C (985-1005°F) | 4-6 hours | Air cool |
ApplicationsMarine & Offshore: Propeller shafts, pump shafts, impellers, valve trim, fasteners, subsea connectors Oil & Gas: Oil well tools, drill collars, downhole equipment, sour gas service components Industrial: Springs, instruments, cryogenic equipment, electronic components
Contact ZYTC Alloy TodayRequest a quote for ASTM B865 UNS N05500 (Monel® K500) – Nickel-Copper-Aluminum Alloy – Precipitation-Hardenable – 2–3× Strength of Monel 400 . Please provide: Diameter / size Product form (bar / square / hexagon / rectangle / forging / wire) Condition (annealed / aged) Length or weight required Quantity Destination port Any special certification requirements
