AMS 5731 is a core aerospace specification governing A286 (UNS S66286 / 1.4980) heat and corrosion-resistant stainless steel. It standardizes bars, wire, mechanical tubing, forgings, flash welded rings, and forging stock with a maximum nominal dimension of 127 mm (5.00 inches), serving as the primary procurement standard for aerospace turbine components and high-temperature structural parts. A286 is a premium iron-nickel-chromium precipitation-hardening superalloy, widely recognized for its balanced high-temperature strength, oxidation resistance and cryogenic stability. Unlike conventional stainless steel, it retains stable mechanical performance at elevated temperatures up to 704°C (1300°F) and maintains non-magnetic austenitic structure down to cryogenic temperatures of -196°C (-320°F). As a professional China aerospace alloy supplier,ZYTC Alloy provides fully AMS 5731-compliant A286 products with standardized solution heat treatment, complete certification and customizable processing to support global aviation and high-end industrial projects. |  |
Chemical Composition| Element | Content (Wt%) |
|---|
| Nickel (Ni) | 24.0 – 27.0 | | Chromium (Cr) | 13.5 – 16.0 | | Titanium (Ti) | 1.90 – 2.35 | | Molybdenum (Mo) | 1.0 – 1.5 | | Vanadium (V) | 0.10 – 0.50 | | Carbon (C) | 0.08 max | | Iron (Fe) | Balance |
Physical & Mechanical Properties| Property | Metric | Imperial |
|---|
| Density | 7.92 – 8.0 g/cm³ | 0.286 lb/in³ | | Modulus of Elasticity | 201 GPa | 29,000 ksi |
Mechanical Properties (Solution Treated – AMS 5731): | Property | Metric | Imperial |
|---|
| Tensile Strength (min.) | 896 MPa | 130 ksi | | Yield Strength (0.2% offset, min.) | 586 MPa | 85 ksi | | Elongation (min.) | 15% | 15% | | Hardness | ≥201 HB | ≥201 HB |
Mechanical Properties (Solution Treated & Aged – AMS 5732): | Property | Metric | Imperial |
|---|
| Tensile Strength (min.) | 896 MPa | 130 ksi | | Yield Strength (0.2% offset, min.) | 586 MPa | 85 ksi | | Elongation (min.) | 15% | 15% |
Heat TreatmentSolution Treatment (AMS 5731): 982°C (1800°F) × 1 hour minimum, oil or water quench Precipitation Hardening (Aging): 704-760°C (1300-1400°F) × 16 hours, air cool
Note: The 1800°F solution treatment produces the highest creep-rupture strength in aged material . Alternative Condition (AMS 5737): 899°C (1650°F) solution treatment and aging provides improved room temperature strength and ductility.
Product AvailabilityZYTC Alloy maintains complete inventory and customized production capacity for AMS 5731 A286 stainless steel. Our product coverage meets diversified procurement needs of aerospace and industrial customers: Main product forms: Sheet, strip, plate, round bar, flat bar, square bar, hexagon bar, forging stock, wire and welding wire Bar size range: Stock diameters from 0.1875 inches to over 14 inches, supporting standard-length supply and custom saw cutting
All supplied materials are delivered with complete CMTR mill test reports, including solution heat treatment records, chemical component analysis and mechanical performance certification, achieving full material traceability.
SpecificationsAMS 5525 Sheet / Stirp / Plate
AMS 5723 (cancelled)
AMS 5726 Bar Work Str 200ksi min
AMS 5731 Bar 1800°F Sol Trtd
AMS 5732 Bar 1800°F Sol Trtd /Aged
AMS 5734 Bar 1650°F Sol Trtd
AMS 5737 Bar 1650°F Sol Trtd /Aged
AMS 5853 Bar Cold Red 160ksi min
AMS 5858 Sheet / Strip (welding gr)
AMS 5895 Bar |  |
Typical Industrial & Aerospace ApplicationsWith its unique high-temperature strength, cryogenic stability and non-magnetic properties, AMS 5731 A286 alloy is widely used in key high-reliability components: Aerospace Field: Jet engine parts, gas turbine components, aviation high-strength fasteners and structural forgings High-Temperature Industry: Industrial high-temperature equipment, heat-resistant structural parts and high-pressure mechanical components Cryogenic Engineering: Low-temperature non-magnetic structural components that require stable toughness
Why Choose ZYTC Alloy AMS 5731 A286 Stainless SteelStrict standard execution: Precisely implements AMS 5731 fixed-temperature solution annealing and rapid cooling process to ensure stable mechanical properties of each batch Full product chain supply: Covers plates, bars, wires and forgings to realize one-stop procurement Complete certification system: Provides official CMTR test reports to support aerospace project inspection and acceptance Flexible customization: Supports non-standard size cutting, personalized processing and customized temper matching
Contact UsRequest a quote for AMS 5731 / A286 Stainless Steel Bar (UNS S66286 / 1.4980) – Iron-Nickel-Chromium Alloy – Solution Heat Treated at 1800°F – High Strength to 1300°F. Please provide: Diameter / size Product form (bar / forging / tubing / ring) Length or weight required Quantity Destination port Any special certification requirements
