AMS 5950 / AMS 5914 Alloy 718SPF (UNS N07719) Sheet

Inconel 718SPF (UNS N07719) sheet offers 180 ksi tensile strength, ultra-fine grain structure (ASTM 10), and superplastic forming capability at 1750°F. Ideal for complex aerospace engine components, ducting, and airframe structures. ZYTC Alloy is AS9120B and ISO 9001 certified.

Quantity :

Contact Now

ZYTC Alloy, a trusted Chinese manufacturer and supplier of high‑end aerospace nickel‑base superalloys, provides premium AMS 5950 & AMS 5914 Alloy 718SPF (UNS N07719) sheets and strips. Alloy 718SPF is a specially optimized superplastic‑forming variant of conventional Alloy 718, engineered for producing intricate, near‑net‑shape aerospace components operating under combined high‑temperature, high‑stress and corrosive service conditions.

Material Overview

AMS 5950 specification governs corrosion‑ and heat‑resistant nickel‑alloy sheet and strip with nominal thickness up to 0.080 inch (2.03 mm), while AMS 5914 covers the expanded specification range for Alloy 718SPF sheet, strip and foil. Designated UNS N07719, Inconel® 718SPF retains the outstanding corrosion‑resistance performance typical of nickel‑chromium superalloys. It fully satisfies mechanical property requirements of AMS 5596G for annealed‑plus‑aged condition, in addition to all dedicated requirements defined within AMS 5950.

Unlike standard Alloy 718, 718SPF is precisely tailored for superplastic forming (SPF) technology. Strict controls over chemical composition, melting route and cold‑rolling schedules deliver uniform fine‑grain microstructure, enabling exceptional superplastic deformation capacity at elevated temperature. This material solves long‑standing manufacturing bottlenecks for complex thin‑wall aerospace structures.

Core Advantages of Alloy 718SPF

Optimized for Superplastic Forming: Controlled fine‑grain microstructure enables large‑deformation SPF, producing highly complex single‑piece components with minimal joints.
Excellent High‑Temperature Performance: Maintains high strength, creep resistance and oxidation resistance under combined thermal load and mechanical stress.
Outstanding Corrosion Resistance: Reliable resistance against various corrosive media, consistent with standard Inconel 718 performance.
Lower Manufacturing Costs: Reduces welding assemblies, part count and secondary machining operations, improving component integrity and reliability for both military and commercial aircraft programs.
Fully Qualified Aerospace Grade: Complies with AMS 5596G, AMS 5950 and AMS 5914 aerospace specifications for critical airborne hardware.

Available Product Range at ZYTC Alloy

ZYTC Alloy supplies Alloy 718SPF sheet, strip and foil conforming to AMS 5950 and AMS 5914. Thickness range covers thin gauges up to 2.03 mm for SPF processing. We keep standard‑size stock for quick lead‑time delivery and accept custom dimensional requirements per customer drawings.

Every production batch undergoes complete metallurgical inspection, including microstructure verification to guarantee superplastic forming capability. Full MTR documentation is provided, and third‑party independent testing is available upon request for aerospace project traceability.

Chemical Composition

Elements	Content (%)
S	≤0.002%
C	≤0.05%
P	≤0.015%
N	≤0.01%
Ti	0.65%~1.15%
Nb	4.75%~5.25%
Cu	≤ 0.30%
Mo	2.80%~3.30%
Ni	50.0%~55.0%
Si	≤ 0.35%
Mn	≤ 0.35%
B	≤0.006%
Al	0.20%~0.80%
Co	≤ 1.00%
Ta	≤ 0.05%
Fe	≥ 11.4%
Cr	17.0%~21.0%

Physical Properties

Density	g/cm³	8.22
Density	lb/in.³	0.297
Melting Range	°F	2300 - 2437
Melting Range	°C	1260 - 1335
Specific Heat	Btu/lb-°F	0.104
Specific Heat	J/kg-°C	435
Curie Temperature	°F	-170
Curie Temperature	°C	-113
Permeability at 200 oersted	15.9 kA/m	1.0011

Mechanical Properties

	INCONEL alloy 718SPF Annealed	AMS 5596G Solution Annealed	AMS 5950 Solution Annealed
Room Temperature Tensile Properties
0.2% Y.S., ksi (MPa)	120 (829)	80 (552) max.	155 (1069) max.
U.T.S., ksi (MPa)	162 (1117)	140 (965) max.	185 (1276) max.
Elongation, %	31	30 min.	20 min.
Hardness, Rc	24	25.5 max.	34 max.
Grain Size, ASTM No.	12	—	10 or finer
		Aged
0.2% Y.S., ksi (MPa)	202 (1393)	150 (1034) min.	148 (1020) min.
U.T.S., ksi (MPa)	225 (1551)	180 (1241) min.	180 (1241) min.
Elongation, %	16	12 min.	12 min.
Hardness, Rc	45	36 min.	36 min.
1200°F (649°C) Tensile Properties		Aged
0.2% Y.S., ksi (MPa)	160 (1103)	120 (827) min.	120 (827) min.
U.T.S., ksi (MPa)	177 (1220)	145 (1000) min.	145 (1000) min.
Elongation, %	22	5 min.	5 min.
1200°F (649°C) /100 ksi (690 MPa) Stress Rupture Properties		Aged
Life, h	95	23.0 min.	23.0 min.
Elongation, %	11.2	4 min.	4 min.

Applications

Alloy 718SPF is the material‑of‑choice for superplastic forming in commercial aviation, military aircraft and related high‑temperature industrial sectors:

Complex thin‑wall SPF aerospace structural components
Aero‑engine static hot‑section sheet metal parts
Aircraft skin panels, ductwork and heat‑shield assemblies
Defense equipment components requiring high‑temperature strength & corrosion resistance
Industrial hardware manufactured via superplastic forming technology

Why Source Alloy 718SPF from ZYTC Alloy

Producing qualified 718SPF demands rigorous control over melting, grain refinement and rolling parameters. As an experienced Chinese aerospace superalloy supplier, ZYTC Alloy executes full‑process quality control for AMS 5950 / AMS 5914 Alloy 718SPF sheet & strip. We guarantee consistent fine‑grain microstructure, stable mechanical properties and reliable superplastic formability for SPF manufacturers worldwide.

Whether you require off‑the‑shelf stock sheets or custom‑sized SPF‑grade strips, contact our engineering team to obtain datasheets, process guidance and competitive factory quotations.
